中船重工722研究所
CSIC 722 Research Institute,
Wuhan (Planning and Architectural Design)
项目地点 武汉市藏龙岛
项目业主 中船重工
设计时间 2004年
竣工时间 2007年
建筑面积 20950m2
Location Canglong Island, Wuhan city
Owner China Shipbuilding Industry Coproration
Design Date 2004
Completed Date 2007
Gross Built Area 20950m2
这是一个研究深水雷达的高技术研究所,该所在武汉藏龙岛购得500亩土地,我们中标了该所的总体规划和主体建筑设计。
主体建筑包括办公室和实验室两部分。从城市关系角度考虑,主体建筑应设置西向主入口,但从气候角度考虑,西向是最不利朝向。故本设计在西向采用双层玻璃幕墙,夏季以层间遮阳和下进上出的流动空气减少主入口门厅的得热量。办公区则以层层退台来减少对城市空间的压力,同时为吸烟者提供吸烟及观景的场所。本项目采用半地下式停车场,在抬高主体建筑的同时,为停车空间提供了自然通风和采光。为了把控西向双层玻璃幕墙的真实效果,我们做了1:1的足尺实验舱,为了确保立面的完成度,我们要求施工方做了许多1:1的足尺构件,在此基础上修改完善施工图。
his is a high technology research institute for deep water radar. The institute purchased 500 mu of land in Canglong Island, Wuhan, and we undertook the general planning and main building design of the institute.
The main building consists of two parts including offices and laboratories. Considering from the perspective of urban relations, the main building should be equipped with a west-facing main entrance. Conversely, from the perspective of climate, the west-facing is the most unfavorable orientation. Therefore, this design adopted double-glazing curtain wall in the west direction to reduce the heat gain of the main entrance foyer in summer by shading between floors and flowing air in and out. The offices utilize layers of back sets to reduce the pressure on the urban space, and provide smoking and viewing spaces for scientists who smoke. The project adopted a semi-underground parking lot, which elevates the main building while providing natural ventilation and lighting for the parking space. In order to control the real effect of the west-facing double-gazing curtain wall, we made a 1:1 full-size laboratory. In order to ensure the completion of the facade, we required the construction side to produce many 1:1 full-size components, on which basis the construction drawings were modified and improved.
建筑方案 李保峰,丁建民,杨欢欢,王力,张波 等
园区规划 丁建民,卢晓刚
施工图组成员 金薇,张华,申安付,甘文霞,姚江波 等
建筑摄影 田方方
Architecture Design LI Baofeng, DING Jianmin,YANG Huanhuan, WANG Li, ZHANG Bo,etc.
Park planning DING Jianmin, Lu Xiaogang
Technical Design JIN Wei, ZHANG Hua, SHEN Anfu, GAN Wenxia, YAO Jiangbo,etc.
Photographer TIAN fang fang
