第十届中国国际园博园(武汉)长江文明馆
Yangtze River Civilization Museum in the 10th China International Garden Expo Park, Wuhan (Architectural Design, win the biding in collaboration with Herzog & De Meuron Architekten)

项目地点武汉汉口
项目业主 武汉园博发展有限公司
设计时间  2013年
竣工时间  2015年
建筑面积  31080㎡

Location   Wuhan city,Hubei province
Owner      Wuhan Expo Park Development Co. LTD
Design Date      2013
Completed Date        2015
Gross Built Area         31080㎡

这是一个关注城市尺度和基于城市眼光的设计。百年前的张公堤和近20年建设的三环线将武汉西北侧的城市空间强行分离。利用建设园博园的机会,景观设计师将张公堤以北肮脏的垃圾山改造为优雅的城市公园,我们则在张公堤南侧设计了能够融入环境的长江文明馆,该馆的绿色屋面与缝合城市的步行桥形成了整体,3.5万平方米的体量巨大的建筑被“肢解”为随着地形层层跌落的、尺度适宜的条状建筑和若干小尺度广场,茂密的绿化则消解了超长建筑体量的冗长感。
在建筑设计层面中我们有如下考虑
(1)空间形态:本设计结合三角形场地,做出南短北长、南低北高的整体空间形态,使得建筑尽可能多地得到来自南侧的阳光和自然风;
(2)通风采光:使用可开启天窗,兼顾通风与采光双重需求。为保证更好的通风效果,我们在天窗上设置了白色张拉膜,张拉膜与天窗之间产生的文丘里效应,有利于提高通风效率;(3)遮阳防热:我们根据不同部位的需求设置了多种形式的遮阳板:建筑的南侧使用镂空式金属遮阳;入口大厅使用了侧面开敞的双层玻璃屋面,在两层玻璃之间针对夏季太阳高度角设置了竹筏遮阳系统;屋面天窗上部的张拉膜则有助于柔化通过天窗进入室内的光线;
(4)地源热泵:我们在门厅、展厅及多功能厅等大空间区域采用垂直埋管式地源热泵,以此为空调系统提供冷热源。

This design focused on urban scale and based on urban vision. The urban space on the northwest side of Wuhan have been forcibly separated by Zhanggong Dike since a century ago and third ring road since nearly 20 years ago. Taking the opportunity of constructing the Garden Expo Park, the landscape architect transformed the dirty garbage mountain to the north of Zhanggong Dike into an elegant urban park. In the south side, we designed the Yangtze River Civilization Museum merging into the environment. The Museum's green roof and the pedestrian bridge which sutured city are formed as a whole. Mega buildings with 35, 000 square meters are "mutilated" to follow the fall of terrain layer upon layer, strip buildings with suitable scale and several small-scale squares. And the dense greenery weakens the continuity of the building.

德方团队   Thomas Herzog,Lingyun Zhang,Roland Schneider,Zhuoyin Zhu,Yann Friedl,Jie Tang
中方团队   李保峰,卢南迪,赵申,金梦漪,梁明,Pavlina,聂华波,王小文,雷育祥,张华,胡俊华,金铃,黄磊,汪蓉,沈世莹,王华鹏,袁旭动, 何建宏 等
建筑摄影 田方方,冯蔚

Germany Design Team:
Thomas Herzog,Lingyun Zhang,Roland Schneider,Zhuoyin Zhu,Yann Friedl,Jie Tang
China Design Team:
LI Baofeng, LU Nandi, ZHAO Shen, JIN Mengyi, LIANG Ming, Pavlina,NIE Huabo, WANG Xiaowen, LEI Yuxiang, ZHANG Hua, HU Junhua, JIN Ling, HUANG Lei, WANG Rong, SHEN Shiying, WANG Huapeng, YUAN Xudong, HE Jianhong,etc.
Photographer   TIAN fang fang,FENG Wei
